Ogi12002824 Hybrid amplifier Receiver Module

Hybrid amplifier Receiver Module

Ogi12002824 Hybrid amplifier Receiver Module

Key Features

● Excellent linearity
● Extremely Low Noise
● Excellent Flatness
● Excellent Return Loss Properties
● GaAs MMIC
● High Reliability

Ogi12002824 Hybrid amplifier Receiver Module

Hybrid amplifier module operating over a frequency range of 40 to 1200 MHz at a voltage supply of +24V(DC)

Type Downstream
Frequency Min(MHz) 40
Frequency Max(MHz) 1200
Output Voltage(dBmV) 35
Return Losses(dB)S22 -10
Pin(mW) 3
CTB(dBc)  -65
CSO(dBc)  -63
CNR(dB)  51
Flatness (dB) ±0.75
Voltage(V) 24
Current(mA) 260-300
RoHS  Yes
 Lead Free
 Yes
Halogen Free Yes or No
