MMIC-SG101 mmic linear amplifiers

Mmic Linear Amplifiers

MMIC-SG101 mmic linear amplifiers

Key Features

●  High linearity: +43dBm OIP3
●  Wide Bandwidth: 45-1218MHz
●  P1dB: 26dBm
●  Low Noise: 2.0dB
●  Input Output 75 ohm Match
●  Single Power Supply: +8V

MMIC-SG101 mmic amplifiers

Sanland’s SG101 is intended for use in applications requiring high linearity, such as CATV Fiber Receiver and Distribution Amplifiers, and CATV Drop Amplifiers.SG101 is RoHS compliant and offered in SOT89 leadfree package.






Type Downstream
Frequency Min(MHz) 50
Frequency Max(MHz) 1,218
Gain(dB) 16.2
CSO(dBc) – 68
CTB(dBc) – 70
NF(dB) 2
Voltage(V) 8
Current(mA) 125
Package Type SOT-89
RoHS Yes
Lead Free Yes
Halogen Free Yes or No



Major Applications

    • CATV Network
    • FTTB Network
    • FTTH Network
    • PON ONU



Absolute Minimum Range and Maximum Application Conditions

Parameters                                      MIN TYP MAX UNIT
Frequency                                        50 - 1218 MHz
Operating Voltage                  5 8 10 V
Application Temperature                  -40 - 85
Operating Junction temperature    150
