Key Features
| ● Excellent linearity |
| ● Extremely low noise |
| ● Excellent return loss properties |
| ● High gain |
| ● High reliability |
Egi10002524D1 Power Doubler Module
Hybrid amplifier module operating over a frequency range of 40 to 1003 MHz at a voltage supply of +24V(DC) ,employing GaAs MMIC.
| Type | Downstream |
| Frequency Min(MHz) | 40 |
| Frequency Max(MHz) | 1003 |
| Input return loss(dB) | -16 |
| Output return loss(dB) |
-16 |
| Slope(dB) | 1. 0-2.5 |
| Gain (dB) | 26 |
| CTB (dBc) | -60 |
| Xmod (dBc) | -55 |
| CSO (dBc) | -63 |
| NF(dB) | 5.0 |
| Flatness(dB) | ±0.5 |
| Voltage(V) | 24 |
| Current(mA) | 330-400 |
| Rohs | Yes |
| Lead Free | Yes |
| Halogen Free | Yes or No |
